Interior / Exterior
Exterior
Minimum Door Thickness
1.625 in
Security/ANSI Grade
ANSI Grade 1
Features
Easy Installation, Adjustable Backset, Rekeyable
Deadbolt Strike
Round Corner
Hardware Finish Family
Zinc
Door Locks & Knobs Product Type
Keyed Handlesets
Total Number of Keys Included
2
Electronic / Mechanical
Mechanical
Knob / Lever Strike
Round Corner
Included
Hardware, Installation Instructions, Drilling Template, Self Guiding Screws
Single or Double Cylinder Deadbolt
Single
Deadbolt Type
Single Cylinder Deadbolt
Commercial/Residential
Residential
Handleset Product Type
2 Piece Front & Back
Knob / Lever Housing Width
5.1 in
Deadbolt Strike Width
1.6 in
Outside Bottom Handle Plate Length
3.1 in
Inside Top Plate Length
2.5 in
Knob / Lever Bore Hole Diameter
2.2 in
Outside Handle and Key Plate Width
2.9 in
Deadbolt Throw Length
1 in
Handle Grip Length
12.9 in
Inside Top Plate Width
2.5 in
Deadbolt Strike Height
2.3 in
Knob / Lever Strike Height
2.3 in
Knob / Lever Throw Length
0.4 in
Knob / Lever Strike Width
0.9 in
Deadbolt Bore Hole Diameter
2.2 in
Deadbolt Trim Ring Diameter
2.5 in
Outside Bottom Handle Plate Width
2.8 in
Deadbolt Cross Bore Diameter
1 in
Maximum Door Thickness
1.75 in
Outside Handle Plate On - Center Measurement
7 in
Outside Handle and Key Plate Length
3.3 in
Knob / Lever Cross Bore Diameter
1 in
Knob / Lever Housing Height
2.8 in
Assembled Height
17.8125 in
Dimensions
16.25 × 8 × 3.88 in
